Shacman F3000 400HP Heavy Duty Dump Truck with 400L Fuel Tank Air Suspension Seat and U-shape Dump Body

The Shacman F3000 6x4 Dump Truck is engineered for heavy-duty applications in construction, mining, and logistics. With a powerful 400HP engine, reinforced chassis, and large payload capacity, it is ideally suited for Lagos, Nigeria's demanding road and project conditions.

• Brand: Shacman
• Model: F3000 6x4 Dump Truck
• Drive Type: 6x4 (Left Hand Drive, optional Right Hand Drive)
• Engine: Weichai WP10.400E32 / 400HP, Euro II/III emission standard
• Horsepower: 400 HP
• Displacement: 9.7L
• Transmission: Fast brand 10JSD/12-speed manual gearbox
• Clutch: Reinforced single dry plate, 430 mm
• Axle:
  • Front Axle: 7.5T
  • Rear Axle: 16T double reduction, hub reduction optional
  • Ratio: 4.77 / 5.73 available
• Suspension: Leaf spring, reinforced, front 9 + rear 12
• Frame: 8 + 8 + 8 mm double-layer high-strength steel
• Steering: Hydraulic power steering, ZF technology
• Brakes: Air brake system, ABS optional
• Cabin: F3000 high-roof cabin with A/C, sleeper, adjustable seats
• Fuel Tank: 400L aluminum alloy

• Type: U-shape or square box
• Box Size: 5600-5800 × 2300 × 1500 mm (customizable)
• Material: High-strength steel Q345 / NM450
• Thickness: Bottom 8-10 mm, side 6-8 mm
• Capacity: 25-30 tons payload
• Hydraulic System: HYVA brand cylinder for fast lifting

• Overall Dimensions (L × W × H): 8614 × 2490 × 3450 mm
• Wheelbase: 3775 + 1400 mm
• Curb Weight: 12,500-13,000 kg
• GVW (Gross Vehicle Weight): 25,000-30,000 kg
• Max Speed: 80-90 km/h

• Hauling sand, gravel, and asphalt for road projects
• Quarry and mining transport (limestone, granite)
• Bulk material movement in ports (Apapa, Lekki)
• Waste disposal and municipal projects
